You are here: Home / Products / Tableware Trible – Headed Glazing Machine Tableware Trible – Headed Glazing Machine
| Technical Data | |
|---|
| Number of Triplex Heads | 18 adet / units |
| Diameter of Glazed Piece | max. 320 mm |
| Number of Produced Products | max. 55 mm |
| Number of Produced Products | max. 600 adet/saat |
| Vacuum Pressure | max. 200-250 bar |
| Lower Reducer Electrical Power | aprox. 2,2 kW, 1500 devir |
| Lower Reducer Braking | max. 32 Nm |
| Arm Motion Motor Power | max. 0,37 kW |
| Plate Transfer | max. 1,5×3=4,5 kg |
| Plate Transfer X Axial Stroke | max. 1100 mm |
| Plate Transfer Z Axial Stroke | max. 250 mm |
| Required Pressure | aprox. 200 bar |
| Net Weight (Body) | aprox. 600 kg |
| Dimensions | 4700 x 4000 x 2450 mm |
